Can Body Assembly Line for Round Cans
The Can Body Assembly Line for Round Cans (METROUNDPACKER) is designed to form and assemble round can bodies by integrating multiple operations into a single, compact system. The line performs processes such as flanging, top and bottom seaming, beading for food cans, expanding for pails, necking, and flanging, ensuring efficient and consistent production.
Key features
• Compact and space-efficient machine design
• Modular system supporting variable tin can production, including open-top and two-side seamed cans, as well as straight and conical shapes
• 15-inch touchscreen with user-friendly operation
• Industry 4.0 compatible architecture
• Fully automatic height adjustment with servo-driven systems
Optional stations
Additional stations can be designed and integrated into the METROUNDPACKER upon request, allowing flexible customization based on production requirements:
• Double flanging
• Top and Bottom seaming
• Conical shaping head
• Necking and flanging
• Beading for food cans or pails
• Pail top edge double curl
• Handle lug welding for wire or plastic handles
• UN upgraded seam
• Lid feeding conveyor system
| MP-RA100 | MP-RA200 | MP-RA300 | MP-RA400 | |
|---|---|---|---|---|
| Production capacity | 100 cans per minute | 90 cans per minute | 80 cans per minute | 60 cans per minute |
| Minimum diameter | 55 mm | 99 mm | 99 mm | 140 mm |
| Maximum diameter | 120 mm | 155 mm | 175 mm | 230 mm |
| Height Range | 50 - 150 mm | 100 - 250 mm | 150 - 350 mm | 150 - 350 mm |
